◎EPC (edge positioning control) device:Ultrasonic sensor
◎Waste discharge function
◎Magnetic brake and clutch
◎Length counting function, automatically stop after it reaches the length you set.
◎2 rewinding inflatable shafts, easy for unloading materials.
It is applicable for slitting industrial tape, electronic material, protective film, copper foil, aluminum foil, OPP, PE, PVC, sheet, cloth, etc. This machine is widely used in the industries such as printing, packing, 3C, leather, garment, plastic, etc.
Model | HX-1300FQ | HX-1600FQ |
Max feeding width | 1300mm | 1600mm |
Power | 6kw | 6kw |
Speed | 80米/分钟 (m/min) | 80米/分钟 (m/min) |
Size | 2400x2000x1300mm | 2400x2300x1600mm |
Weight | 1200kg | 1500kg |
Max.unwinding diameter | 800mm | 800mm |
Max.rewinding diameter | 450mm | 450mm |
Precision | ±0.1mm | ±0.1mm |
Power | 380V 50Hz | 380V 50Hz |
